HUIBO Best PEX Fittings

Uses: Water Supply/Pipe Connect

Connection method:Thread/Tools

Advantages of IFAN products: Free samples, high quality, cheap price, support custom.



PEX compression fittings are essential components used in plumbing systems to connect PEX pipes. In this article, we will explore the different types of PEX compression fitting, their materials, structures, and the step-by-step process of connecting them.

Product Name IFAN PEX Compression Fittings
Color Yellow,Silver,Double Color Or Customized
Size 16-32mm
Material Brass
 Package OPP Bag+Carton
OEM Aviable
Sample Free Provide
Contact US Whatsapp:+8613373827623 E-mail:[email protected]

Types of HUIBO PEX Compression Fittings:

1.Straight Coupling: Used to connect two PEX pipes in a straight line without any deviation.
2.Elbow: Enables a change in direction by connecting two PEX pipes at a 90-degree angle.
3.Tee: Connects three PEX pipes together, allowing for branching connections.
4.Reducer: Facilitates the connection between PEX pipes of different diameters.
5.Valve: Incorporates a shut-off mechanism, providing control over the flow of water.

Materials Used in PEX Compression Fitting:

1.Brass: The most common material due to its excellent durability and resistance to corrosion.
2.Stainless Steel: Offers high strength and corrosion resistance, making it suitable for various applications.
3.Polymer: Provides a cost-effective alternative, especially in non-critical applications.
Structure of PEX Compression Fittings

PEX compression fitting consist of several key components:

1.Compression Ring: Made of brass or stainless steel, it compresses the HUIBO PEX pipe onto the fitting, creating a tight seal.
2.Compression Nut: Holds the compression ring in place and provides a means of tightening the fitting.
3.Body: Forms the main structure of the fitting and connects to the PEX pipe.
4.Insert: Used in certain fittings to support the PEX pipe and prevent collapse under pressure.

Connecting PEX Compression Fitting: Step-by-Step Process:

1.Cut the PEX pipe to the desired length using a pipe cutter, ensuring a clean and square cut.
2.Slide the compression nut and compression ring onto the pipe.
Insert the pipe into the fitting until it reaches the bottom.
3.Slide the compression ring up to the fitting, ensuring it is positioned over the pipe.
4.Tighten the compression nut onto the fitting using a wrench until it is securely in place.
Perform a pressure test to check for any leaks.

Advantages of PEX Compression Fittings:

1.Versatility: PEX compression fittings can be used with various pipe materials, including PEX, copper, and CPVC.
2.Easy Installation: The step-by-step process is straightforward, allowing for quick and hassle-free connections.
3.Reusability: Compression fittings can be disassembled and reused if necessary, making them cost-effective.
4.Durability: The brass or stainless steel construction ensures a long service life and resistance to corrosion.
